Home > Gantry > cnc double column machining center
cnc double column machining center

Modle:GS1525

Features:
high speed and high rigidity
Packing:
Wooden Case,Standard packing
Key Specification:
  • 2500
    X axis travel/mm
  • 1500
    Y axis travel/mm
  • 800
    Z axis travel/mm
  • 40-6000
    Spindle speed/rpm
  • 2500*1300
    Table size/(L*W)
  • Fanuc 0i MF-M1
    Control system
Product Details Specification
Strong cutting capacibility
The most excellent response system for counter-balance Z-axis

The most excellent strength in structure

The advanced control system
The spindle box is designed on the base of the most applicable rectangular ratio with inside structured by interlayers and arcuated ribs
Special staged propping system with 3 sliders on upper guideway and 3 RG series roller-type sliders makes the travelling range od sliders on the guideway reach 50%-70% of guideway length,deserving a super strength and stability.
The maximized feeding structural system
The most applicable spindle box
The most excellent feeding system
Our columns have adoped box-type structural column and machine weight has increase 25%.
The machine base is made in the form of box-type structure and chip removal slots from one-body formed stout base wall and rib plates have strngthened static rigidity and dynamic accuracy of machine base.
With box-type and staged strctural design, the crossbeam has best moment of inertia for resistance to bending, ensuring the work of machine on Y axis and Z axis with static orecision.
With special closed double-deck sructure, high rigid roller-type slider and RG guideway with best space the bottom,the travelling distance of slider on work table has reachied 25% of table length in this gantry cnc.

 gantry cnc

 gantry cnc

 gantry cnc

 gantry cnc

gantry cnc
