Are your machining centers stable enough?
	Gantry type double column with higher stability than the C type. Short throat deep ( distance between column guide rail surface and spindle),it can avoid the shake of ferrous metal cutting.

Workbench fully supported

Gantry type double column with higher stability than the C type.
Short throat deep ( distance between column guide rail surface and spindle),it can avoid the shake of ferrous metal cutting.

Four rail lines ram patented technology in this cnc milling machine, which is 30% efficiency added than large vmc.

Are you still worry about site?

Save you 1/3 of plant
Square shape design,In meet the effective processing,
save 1/3 plant than the vertical machining center.

3″ VS 6 ″
1/2 tool change time

Composite spindle and tool storage， reduce tool change time

Details of the user-friendly design

We not only focus on the design of machine rigidity and stability,
but also consider the needs of users actual use demand, such
as two work lamp, two screw conveyor and automatic chip removal. cnc milling machine

cnc milling machine

We have been insisting on the principle of customer first,from product research and development, procurement, production, testing, packaging,
transportation, we do every step the best.Give careful consideration to the needs and expectations of customers.

cnc milling machine

Model No. vmc machine price listc milling machine	GQ700	GQ800	GQ900	GQ1300	GQ1500
Travels
X axis travel/mm	1100	1300	1100	1300	1600
Y axis travel/mm	700	800	900	1300	1500
Z axis travel/mm	600	600	600	600	600
Spindle nose to worktable/mm	150-750	150-750	150-750	150-750	150-750
Worktable
Table size(L*W)	1100x700	1300x800	1000*800	1300x1300	1500x1000
Gate width/mm	900	1100	1100	1400	1600
Max load on the table/kgs	900	1000	1000	1500	2500
Spindle
Spindle speed/rpm	160-8000
Spindle taper	7/24 Taper No.50
Spindle motor/kw	11/15
Feedrate
X,Y axis rapid traverse(M/min)	36
Z axis rapid traverse(M/min)	24
Max cutting feedrate(mm/min)	10-10000
A.T.C
Toolmagazine capacity(opt)/pcs	Arm type 24
Max exterior tool diameter/mm	φ150(80)
Max tool length/mm	300
Max tool weight/kgs	8
Tool change time/sec（T-T）	4.5(Arm Tpye)
Motor
Z axis Spindle motor/kw	7.5/11
X axis AC servo motor/kw	3.5
Y Z axis AC Servo motor/kw	3.5
Shield	Full cover
Color	Standard
Control system	FANUC-0i mate MD

Main machine configuration cnc milling machine	1.cnc milling machine control system: FANUC-0imate MD (full set)
	3.axis servo motor: FANUC from Japan
	2.Arm type A.T.C with 24 tools,
	3.10000rpm high speed 7/24 Taper No.40 Spindle
	4.Spindle bearing
	5.Crew type chip removal system
	6.heat exchanger
	7.heavy-load linear guide rails on X/Y axis
	8.automacti lubrication system
	9.work and alarm lamps
	10. releasing tool device
	11.coolant system
	12.fully enclosed splash guard
	13.rigid tapping
	14.standard accessories
Main parts supplier cnc milling machine	1.controller: FANUC 0i mate MD from Japan
	2.spindle motor: Fanuc from Japan
	3. 3 axis servo motor: Fanuc AC servo motor from Japan
	4. spindle bearing: NSK/FAG(P4 grade) from Japan
	5. x/y/z axis bearing: NSK/FAG (P4 grade) from Japan
	6.x/y/z ball screw: HIWIN(C3 grade) from China Taiwan
	7.spindle unit: KENTURN from China Taiwan
	8. A.T.C system: from China Taiwan
	9.lubricator system: from Japan
	10.heat exchanger: from China Taiwan
	11.electrical components: from China Taiwan(cnc milling machine)
